Outdoor LED P5 Display – Durable, High-Quality Advertising Solution
Product description
Outdoor LED P5 Display – Durable, High-Quality Advertising Solution
1. Product Introduction
The Outdoor LED P5 Display is one of the most popular products in the outdoor LED screen category, featuring high resolution (up to 4K support), excellent weather resistance, and an optimal viewing distance—delivering exceptional value for advertising and business promotion.
With a pixel pitch of 5mm, the Outdoor LED P5 is specifically designed to operate in harsh outdoor environments. It features water and dust resistance, and high brightness levels, ensuring vivid, sharp images even under direct sunlight.
2. The Importance of Outdoor LED P5 Screens in Modern Advertising
-
Brand Visibility:
Vivid images and videos on the Outdoor LED P5 attract passersby, create a strong impression, and boost brand recognition. -
Effective Message Delivery:
Flexible, diverse advertising content helps businesses reach their target customers in an engaging and dynamic way. -
Cost Efficiency:
With a long lifespan and low power consumption, the Outdoor LED P5 helps businesses save significantly on operating and maintenance costs compared to traditional advertising.
3. Technical Specifications of the Outdoor LED P5 Module
Specification | Details |
---|---|
Model | P5 Outdoor |
Pixel Pitch | 5mm |
Pixel Configuration (W×H) | 64×32 pixels |
LED Type | 1R1G1B 3-in-1 SMD2121 |
Brightness | ≥6000 cd/m² |
Operating Temperature | -20°C to +50°C |
Operating Humidity | 10% to 90% RH |
Pixel Density | 40,000 pixels/m² |
Color Temperature | 6500K |
Viewing Angle (Horizontal/Vertical) | 140° (-70° to +70°) |
Module Size | 320×160mm |
Module Resolution | 64×32 pixels |
Cabinet Size | 960×960mm |
Cabinet Depth | 180mm |
Cabinet Material | Aluminum, galvanized steel, etc. |
Cabinet Weight | 4.2kg/cabinet |
IP Rating (Front/Rear) | IP65/IP65 |
Recommended Viewing Distance | ≥5m |
Color Display | >16.7 million – 281 trillion colors |
Grayscale | 65,536 levels/color |
Brightness Adjustment | 100 levels |
Refresh Rate | 1920Hz |
Input Voltage | 110 or 220VAC |
Max Input Power | 1000W/cabinet |
Average Power Consumption | 450W/cabinet |
Lifespan | 100,000 hours |
Dominant Wavelengths | Red: 620–625nm, Green: 525–530nm, Blue: 470–475nm |
Multimedia Formats | DVI, MPG, AVI, WMV, RM, etc. |
Data Connection | UTP Cat 5e/6, Optical fiber |
Control System | NOVA / HD / KYSTAR / LISTEN |
4. Key Features of the Outdoor LED P5 Display
-
Versatile Applications:
Ideal for advertising, stadium screens, rental screens, malls, banks, stock exchanges, transportation hubs, airports, telecommunications systems, stage performances, and more. -
High Contrast and Refresh Rate:
Ensures vivid, dynamic images that stand out even in bright daylight. -
Vivid, Clear Images:
Maintains exceptional visibility even under direct sunlight. -
User-Friendly Interface:
Easy installation, simple configuration, and a user-friendly interface (Vietnamese available). -
Convenient Maintenance:
Front or rear access for easy maintenance, saving time and costs. -
Energy Efficiency:
Utilizes high-tech FWM semiconductor chips that reduce power consumption by up to 25% compared to standard chips.
5. Applications and Variants of the Outdoor LED P5 Display
-
Advertising, brand promotion, product displays on building facades.
-
Storefronts, showrooms, factories, shopping centers, and more.
-
Lobbies, entrances, schools, hospitals, stations, airports, and telecommunications centers.
In addition to permanent installations, LEDCONGNGHE also offers rental services for short-term advertising needs.
Available solutions:
-
Fixed outdoor screens mounted on buildings.
-
Standalone screens with dedicated support structures.
-
Mobile screens for rental purposes.
-
Custom-designed screens to meet specific project requirements.
6. Important Notes When Choosing an Outdoor LED P5 Display
Outdoor LED P5 prices vary based on supplier, component quality, screen size, and market timing. For the most accurate quote, please contact LEDCONGNGHE directly.
⚠️ Important: Outdoor LED screens are completely different from indoor ones in terms of brightness, water and dust resistance. Avoid using indoor modules outdoors as they are not designed to withstand outdoor conditions and may be damaged easily.
LEDCONGNGHE – Your Trusted Partner for Outdoor LED P5 Displays
LEDCONGNGHE proudly offers genuine, high-quality Outdoor LED P5 displays, backed by transparent sourcing and certifications. Our team of skilled technicians ensures professional installation, maintenance, and customer support.
With a commitment to integrity and reliability, LEDCONGNGHE prioritizes customer satisfaction and long-term partnerships.
👉 Contact us today via LEDCONGNGHE.vn or HOTLINE: 083 339 8839 for personalized consultation and the best deals on Outdoor LED P5 Displays!
