OUTDOOR LED DISPLAY W SERIES – W5
Product description
OUTDOOR LED DISPLAY W SERIES – W5– EFFECTIVE DISPLAY SOLUTION FOR PUBLIC SPACES
The W Series – W.5 outdoor LED display is a reliable and affordable solution designed for large-scale public applications. Ideal for countries or projects with tighter budgets, this series combines high brightness, waterproof structure, and strong performance at a highly competitive price.
As a complementary line to our premium C Series, the W Series focuses on global markets outside the US, offering optimized production costs while maintaining durability, visual clarity, and ease of deployment.
⚙️ KEY SPECIFICATIONS
| ModeNo | W5 | |
| Module | Pixel Pitch (mm) | 5 |
| LED Type | SMD 2727 | |
| Module Dimension (W*H)(mm) | 320x 160 | |
| Module Resolution (W*H)(Pixel) | 64x 32 | |
| Pixel Density (PixeV m²) | 40000 | |
| Scan Mode (S) | 8 | |
| Cabinet | Cabinet Dimension (W*H)(mm) | 960x 960 |
| Cabinet Resolution (W*H)(Pixel | 192×192 | |
| Cabinet Material | Magnesium Alloyl Waterproof Iron | |
| Cabinet Weight (Kg) | 25/30 | |
| Display | Best Viewing Distance (m) | 5 |
| Brightness (nits) | 5500-8000 | |
| Ingress Protection (Fron/Rear) | IP65 | |
| Viewing Angle | H:140°V:140° | |
| Color Temperature | 3200-9500K | |
| Gray Level | 14bit | |
| Max Power Consumption (W/m²) | 750 | |
| Average Power Consumption (W/m²) | 250 | |
| Refresh Rate (Hz | 1920-3840 | |
| Maintenance Method | Rear Maintenance | |
| Operating Temperature | -30℃-80℃ | |
| Operating Humidity | 10%-95%RH | |
| Input Voltage | AC110-220V±15%50-60Hz | |
| MTBF(Hours) | 50000 | |
| Life Time(Hours) | 100000 | |
✅ MAIN ADVANTAGES
-
High Brightness: Up to 8,000 nits, ideal for strong daylight visibility.
-
Budget-Friendly Design: Public mold iron cabinet reduces cost while retaining durability.
-
Fast Delivery: Common pitch types (P5, P6, P8) available in stock.
-
Easy Maintenance: Rear maintenance design requires a 60–80cm service channel.
-
Excellent for Harsh Conditions: Fully waterproof and temperature-resistant.
-
Low Energy Option: Optional common cathode power supply reduces heat and electricity usage—perfect for regions with high energy costs.
🌍 APPLICATION SCENARIOS
-
🏢 Outdoor building facades, malls, and shopping centers
-
🏟️ Stadiums, event venues, concerts, and festivals
-
🚉 Bus stations, transportation hubs, and terminals
-
🏫 Schools, hospitals, industrial zones
📞 Contact Led Công Nghệ today for a customized quote and project consultation.
📬 Email: info@ledcongnghe.com
🌐 Website: www.ledcongnghe.com
📱 Hotline: +84 833 398 839
